For a concrete plant, the number of working cycles per 1 hour is 56. This is subject to continuous operation. A concrete mixer is used at the concrete plant, which gives out 800 liters of concrete mix, that is, 0.8 cubic meters, at the end of each cycle. For one hour of continuous operation, an estimated amount of 45 cubic meters of concrete is produced during 56 cycles, which is the capacity of 45 cubic meters/hour.
Medium-series concrete plants are profitable primarily from an economic point of view, since at a relatively affordable price they can produce a large amount of ready-mixed concrete per shift, and be serviced by a staff of only three persons, which makes them in demand by small enterprises and individual entrepreneurs. Such high capacity, which underlies the success of the concrete plant application, is provided by its technological features.
Each component of the finished equipment is initially focused on the production of large-volume batches with minimal labor costs. Like other technical capacities presented on the market by Zavod Stroitekhnika, this concrete plant "knows" how to work almost in a fully automated mode, which is also a definite plus, because a minimum number of employees is required for its operation and maintenance.
To ensure ease of installation and further use, the standard equipment of the concrete plant includes a U-shaped service ramp necessary to ensure the loading of a concrete truck, on which a mixer with water and cement hoppers and a finished concrete feed funnel are installed. Zavod Stroitekhnika offers to purchase various additional equipment, including: a cement debagger or silo of the required volume, optimally combined with a concrete plant. All production processes of finished products of any type due to automation are intuitive and simple, which makes it possible to simply attract additional employees when increasing the order volume.
The concrete plant is easy to maintain, there is a detailed instruction manual included in the set of equipment provided.
There is a long-term warranty.The Рифей Бетон 45 line has the following technical specifications:
Total power 65 kW;
Total weight 14,740 kg;
Length 19.5 meters;
Width 4.3 meters;
Height 7.8 meters.
