Manufacturing of Rifey and Кondor vibrating presses. Rifey Concrete plants

Official Website

178 640 USD

Rifey Buran-2R-1100-SDA-24 P (packer)

Rifey Buran-2R-1100-SDA-24 P (packer)
  • system

    packaging

  • system

    dosing

  • 15 sec

    molding cycle

  • 210

    rm border. stones / h

We offer the Rifey Buran-750-SD-A vibropressing complex at a favorable price from the manufacturer!   This is an innovative domestic development that has no analogues in Russia . The batching system, equipped with modern electronic batchers of concrete mixture components, is capable of showing high productivity in the production of construction products for various purposes.

- Vibrating table drive, made according to the "mechanical variotronic" scheme . This makes it possible to separately adjust the vibration amplitude (and, therefore, the vibration energy) during loading and forming for products of different heights. Those. when loading the mixture into the matrix, vibration can be set less to exclude too large amplitude of the matrix and concrete mixture, and during molding, the vibration can be adjusted more for maximum compaction of the mixture.

In addition, there are no resonant excitations of the vibration table, which take place in the "BURAN" when the vibration table electric motor is switched on and off. This reduces the dynamic load on metal structures and improves the quality of molded products.

- It is possible to use the option of separate change of vibration frequency   on loading and forming, which can further increase the quality and density of products while reducing the amount of cement. Such regulation is used on foreign vibropresses. There is no need to change the metal structure of the vibropress.

- Possible
Rotary pallet cleaning brush option   on the bottom tier of the module.

Vibropress Rifey-Buran-2R:

Shaping block

Mix loading module

Pallet feeder

Oil station

Automatic control panel

Punch-matrix (any from the catalog)

Shelving unit (1 pc.)

Shelving traverse

Technological pallet (12 pcs.)

53 590 $

Dispensing system 1100-SDA-24:

1. Concrete mixer BP-2G-1100 (two-shaft, V = 1100 l)

2. Block of weighing batchers BD-1100   (cement batcher, water batcher)   CAS strain gauges, batching accuracy ± 1% .

3. Aggregate batcher DZ-24 (2 bins of 12   cubic meters, with the ability to dose 3 components in a proportion of 1-12 cubic meters, and 2 of 6 cubic meters)   Weighing conveyor on 4 strain gauges Cas. Dosing accuracy ± 1%. Each hopper has one vibrator.

4. Control panel PU-SDA (with monitor, recipe memory, etc.).

5. Belt conveyor KL-650-7-120.

6. Belt conveyor KL-650-7-120 Sh with a receiving hopper (chevron belt).

7. Screw conveyor KV-6 (auger),     length 6m.

8. Overpass mixer.
9. Pneumatic equipment, Compressor SB4 / F-270 LB50 "Remeza".

73 167 $

Automatic batching system "P":

1. Bundler .

2. Installation of pumping baler.

3. Pallet feeding module with pallet magazine (pallets).

4. Control panel.

5. Roller table.

6. Module for unloading pallets (4 217 $).

46 052 $

Specifications

Technical parameter

Forming zone, mm

1000х500

Dimensions of the pallet for molding, mm

1150х600х40 ... 50

Height of molded products, mm

30… 300

Productivity, piece / hour:

Hollow stones 390х190х188

800

Partition stones 390x120x188

1100

Side stones BR 100.30.15

210

Paving slabs 200x100x70 m2 / hour

100

Nominal power and speed of the electric motor of the press

18.5 kW

1500 rpm

With the help of these constituent elements, the pressing unit is able to produce such piece concrete products as: wall stone of various types (hollow, solid, partition, thickened, etc.), facing stone, paving slabs of various shapes and sizes, curb stones, various elements of the improvement of houses and territories.

In addition to the conveyor and the container, the complex includes many other important elements. The list of these includes   a powerful hydraulic station , which creates the necessary pressure to form products, as well as a unit that supplies the mixture to special molds. Also, the model is provided with a system for feeding special pallets into the pressing zone of products and a system for delivering them with finished blocks to the racks. Then, using the traverse, the pallets are sent to the drying sector, and from there the rack with empty containers is replenished.

It is worth noting one important feature. The installation uses a shock-type polyharmonic vibration system and an inertial punch operation principle.   This allows you to expand the range of application of various fractions in aggregates, in the manufacture of semi-dry hard concrete mixtures and in general As a result, it guarantees the customer a wide range of building materials produced with the help of this equipment, calculated in a list of more than 300 items.
  • A clear and uncomplicated design of the equipment that allows you to carry out repairs yourself, without involving the plant's specialists. Constant availability of spare parts at a low price on sale.
  • 3-4 people are enough to service the complex, while high qualifications and special knowledge are not required from them.
  • Large selection of interchangeable dies that are responsible for the assortment. Quick change of production from one type of product to another.

All this allows us to say with confidence that there is no similar equipment in Russia. It is also absent in the CIS countries. These are exclusive products of the Stroytekhnika plant.
