- Vibrating table drive, made according to the "mechanical variotronic" scheme. This makes it possible to separately adjust the vibration amplitude (and, therefore, the vibration energy) during loading and forming for products of different heights. Those. when loading the mixture into the matrix, vibration can be set less to exclude too large amplitude of the matrix and concrete mixture, and during molding, the vibration can be adjusted more for maximum compaction of the mixture.
In addition, there are no resonant excitations of the vibration table, which take place in the "BURAN" when the vibration table electric motor is switched on and off. This reduces the dynamic load on metal structures and improves the quality of molded products.
- It is possible to use the option to separately change the vibration frequency at loading and forming, which can further increase the quality and density of products while reducing the amount of cement. Such regulation is used on foreign vibropresses. There is no need to change the metal structure of the vibropress.- Possible option "rotating pallet cleaning brush" on the lower tier of the module.
- Pumping unit. Pump NSh-32. The power of the electric motor (15 kW) and the volume of the tank (300 l) have been increased. Hydraulic equipment is provided for the module of the second layer.
- For the transportation of pallets, metal racks are not required;
- No preparation of a place is required for installing a stack of pallets in the steaming chamber;
- Possibility to adjust the lifting height depending on the height of the product to reduce cycle time;
- Large lifting capacity - 3000 kg,
- High speed of work, time of one cycle - 6 sec.;
