Rifey Кondor 150TB

800
pcs of wall stones per shift
64-72
sq.m of paving slabs per shift
960
m of kerb stones per shift
1200
pcs of partition stones per shift

The ply taken for the total improvement of settlements, towns, cities in the region requires a huge amount of finishing material. For landscaping, it is necessary to have capacities, which could satisfy the growing demand for paving slabs, curbs and other piece goods. Such equipment is produced by Stroytekhnika Plant, located in the city of Zlatoust.

Advantages
Features
Сomposition

Kondor 1-90TB is a quite compact machine; its operation is possible under a canopy, in a small utility room or simply at the production yard of the enterprise.

The capacity of the machine is amazing. Up to 90 of wall stones (700 pcs per 8-hour shift), approximately 9 squares of paving slabs, 120 partition blocks are removed from the matrix every working hour. One dominant advantage is its weight, which is only 1200 kg. Technologically, the assembly unit is quickly installed in working position and also dismounted. It's a real godsend for a small business. A quick switch to the output of new products, matrix and punch are changed within 20-30 minutes.

Scope of supply:

Brick making machine
Punch-matrix
Monobin
Platform
Concrete mixer, V=90 l
Conveyor
Remote control
Pump unit
Racking
Pallets, 5 pcs

Capacity of the machine in the manufacture, pcs/h:
wall stones 390х190х188 mm	100...110
partition stones 390х120х188 mm	150...165
paving slabs 200х100х70 mm (sq.m)	400...450 (8.0...9.0)
Operating personnel, persons	2
Electric power consumption:
voltage, V	380
frequency, Hz	50
installed power, kW	13.0
Overall dimensions of the machine:
length, mm	5000
width, mm	1500
height, mm	2800
Weight of the machine	1215
Adjusted vibration level at the operator's workplace, dBA	less than 70
Polluting emissions	no

Калькулятор прибыли

Вид продукции:

Производительность:

Расчётный период:

Прибыль: руб.

Окупаемость: дней.

Features

Today we can say that Kondor 1-90ТB brick making machine fully justifies all the expectations. Individual entrepreneurs, repair business units in the housing and community amenities system and others buy it. The machine is appreciated for its high performance, low cost, reliability and safe operation. The main feature is its scalability; in case of business expansion the machine can be easily replenished by different options. If you want to bring the production of piece goods to the object, then the dismantling can easily be done in 1 day with a limited number of workers, and it is also possible to install it on the new not even prepared site. It is necessary to provide a flat floor area of 20 sq.m and normal access ways. The operation of the machine is simple and straightforward, no special skills are required to work with it.
